Kirisun PT5200 UHF VHF Walkie Talkie

Q: Do these radios require a license?

Business UHF/VHF radios require a license in most countries; license-free TLKR/PMR models and PoC/LTE radios do not. Contact us and we will advise for your country.

Q: Can you program my frequencies?

Yes — include your licensed frequencies in the order notes and we pre-program the radios before shipping, free of charge.

Q: What range should I realistically expect?

Expect 1–5 km in urban environments and 10 km+ line-of-sight, depending on power, terrain and antenna.

Kirisun PT5200 UHF/VHF Walkie Talkie, 16CH 5W

Bulk pricing available for orders of 10+ units. Get a quote → | Full price list

Kirisun Portable Walkie Talkie Radio Comunicador Professional 2 Way Radio PT5200 16CH 4-10km 5W is a Kirisun two-way radio (model PT5200). Built for daily professional use, it delivers the performance you expect from commercial-grade communication gear. Wholes

Ships From
Color	Clear

30-Day ReturnsFree Return Shipping24/7 Expert Support

Description

Output Power(w): 3w-5w
Battery Capacity(mAh): 1200
Waterproof / Water-Resistant: IP57
Model Number: PT-5200
Walkie Talkie Type: Portable
Is_Display: No
Maximum Range: 5km-10km
Brand Name: KIRISUN
Origin: Mainland China

T5200 General
Frequency Range	136~174MHz, 400~470MHz 470-512MHz, 500~528MHz
Channel Capacity	16
Channel Spacing	12.5KHz/20KHz/25KHz
Operating Temperature	-30℃~ +60℃
Operating Voltage	7.5V DC ±20%
Battery	1200mAh Li-poly(Standard)
Frequency Stability	±2.5 ppm
Dimension(with battery and antenna)	57mm×102mm×30mm
Weight(with battery and antenna)	235g
Transmitter
RF Power Output	4W/2W/0.5W(UHF) 5W/2W/0.5W(VHF)
Frequency Modulation	16KφF3E/11KφF3E
Antenna Impedance	50Ω
Modulation Limiting	±2.5KHz @12.5KHz, ±4KHz @ 20KHz, ±5KHz @ 25KHz
Radiated Spurious Emission	-36dBm < 1GHz -30dBm > 1GHz
FM Noise	40dB @ 20/25KHz 35dB @ 12.5KHz
Modulation Distortion	< 3%
Receiver
Reference Sensitivity	0.28μV @12.5KHz 0.25μV @ 20/25KHz typical
Adjacent channel Selectivity	60dB @ 12.5KHz 70dB @ 20/25KHz
Intermodulation	65 dB
Spurious Response Rejection	70 dB
Rated Audio Output	0.5W
S/N	40/35
Rated Audio Distortion	≤3%

Standard

Do these radios require a license?

Business UHF/VHF radios require a license in most countries; license-free TLKR/PMR models and PoC/LTE radios do not. Contact us and we will advise for your country.

Can you program my frequencies?

Yes — include your licensed frequencies in the order notes and we pre-program the radios before shipping, free of charge.

What range should I realistically expect?

Expect 1–5 km in urban environments and 10 km+ line-of-sight, depending on power, terrain and antenna.
